    Home > Product > RF Cables > LMR 100 cable


 [LMR100]//[LMR200]//[LMR240]//[LMR300]//[LMR400]



RLL-100U

PE insulated Low Loss Cable, 2.8mm(1.1inch) OD, 50ohm

LMR 100 cable structure

MECHANICAL DATA



 ITEM                   MATERIAL               DIAMETER            REMARK



Inner Conductor           Copper Clad Steel                    0.46mm

Dielectric                    Solid Polyethylene                    1.52mm



1st OUTER SHIELD         Unsealed AP Tape

2nd OUTER SHIELD        Tinned Copper Braid        1.97±0.1mm

JACKET                      PVC                    2.79±0.1mm         BLACK





ELECTRICAL DATA



ITEM                                  SPECIFICATION



Min. Bend Radius(mm)                   15

Storage Temp.()                          -25 to +70

Installation Temp. ()                    -25 to +70

Operating Temp.( )                     -25 to +70



Capacitance(pF/m)                         106

Impedance(ohm)                        50+/-5

Velocity(%)                               66

Inner Conductor DC Resistance(/km)     268

Outer Conductor DC Resistance(/km)     31.2

Shielding Effectiveness(dB )                 >90

Product Weight                          14kg/km

Nominal Attenuation

Frequency(MHz)                Attenuation(dB/100m)     Avg. Power(KW)

30                12.90                          0.23

50                16.70                          0.18

150                29.40                          0.10

220                35.80                          0.08

450                51.90                          0.06

900                74.90                          0.04

1500                98.70                          0.03

1800               109.00                          0.03

2000               115.50                          0.03

2500               130.60                          0.02
