RG 178

RG Series, 1.8mm(0.07)OD, 50ohm Specification Mil-C-17/93-RG178

RG 178 cable structure

MECHANICAL DATA



ITEM                     MATERIAL       DIAMETER             REMARK



CENTER CONDUCTOR   SPCW             0.30±0.02mm       Strand 7/0.101mm

DIELECTRIC              PTFE               0.83±0.05mm       SOLID

OUTER SHIELD         SPC                 1.30±0.15mm       95%(nom.)

JACKET                    FEP                 1.80±0.12mm       BROWN

* SPCW: Silver Plated Copper clad steel Wire

* SPC: Silver Plated Copper

* FEP: Fluorinated Ethylene Propylene



ELECTRICAL DATA



ITEM                              SPECIFICATION



CAPACITANCE                     104.9 pF/m (32.0 pF/FT) (nom.)

CHARACTERISTIC IMPEDANCE    50±3

OPERATING FREQUENCY             5 GHz

OPERATING TEMP                   -40 +165

OPERATING VOLTAGE             1,000 vrms (max.)

VOLTAGE WITHSTANDING            2,000 vrms (min)

RoHS Compliant                      YES

WEIGHT                              9 kg/Km

MAXIMUM ATTENUATION

Frequency (MHz)               dB/100ft (dB/M)             Power (Watts)



              100                16.0(0.52)         255

              200                21.6(0.71)         -

              400                33.0(1.08)         113

              800                43.3(1.42)         -

            1,000                52.0(1.70)         66

            2,000                71.0(2.33)         -

            3,000                80.5(2.64)         -

            5,000               110.3(3.62)         -
