 [RSF047]//[RSF085]//[RSF141CW]//[RSF141SPC]//[RSF250]



RSF-047

Semi Flexible (Hand Formable) Cable, 0.047 Size, by Specification Mil-C-17/151 Type

Hand formable cable

MECHANICAL DATA



 ITEM                   MATERIAL       DIAMETER             REMARK



CENTER CONDUCTOR   SPCW               0.27±0.005mm

DIELECTRIC              PTFE               0.94±0.050mm    SOLID

OUTER SHIELD         Tinned Copper      1.19±0.050mm    BRAID/100% COVERAGE



* SPCW: Silver Plated Copper clad steel Wire



ELECTRICAL DATA



ITEM                              SPECIFICATION



BEND RADIUS                    3.2 mm (min.)

CONDUCTOR RESISTANCE         207.3 Ohms/Mft at 20 (max.)

CAPACITANCE                   95.1 pF/m (29.0 pF/ft) (nom.)

CHARACTERISTIC IMPEDANCE  50 +/- 2 ohms

DIELECTRIC CONSTANT            2.07(nom.)

OPERATING FREQUENCY           20 GHz (max.)

OPERATING TEMP                  -40 +125

VELOCITY OF PROPAGATION     69.5 %(nom.)

VOLTAGE WITHSTANDING          3,500 vrms @ 60 Hz

RoHS Compliant                      YES

WEIGHT                             7 kg/km (0.47 lbs/100ft)

MAXIMUM ATTENUATION

Frequency (MHz)                dB/100ft(dB/m)                Power (Watts)



               500                28(0.91)              17.7

             1,000                40(1.30)          11.9

             5,000                98(3.20)               5.1

            10,000               155(5.06)               3.5

             20,000               270(8.82)                -
