 [RMF085(SS 405)]//[RMF141CW(SS402)]//[RMF141SPC)]



RMF-085

Multi Flexible Cable, 0.085 Size, 50ohm 2.62mm OD

multi flexible cable structure

MECHANICAL DATA



 ITEM                   MATERIAL       DIAMETER             REMARK



CENTER CONDUCTOR   SPCW           0.51±0.07mm

DIELECTRIC                PTFE            1.63±0.02mm

1st OUTER SHIELD         SCT              1.78±0.02mm      100%(nom.)

2nd OUTER SHIELD        SPC              2.16±0.02mm      90%(nom.)

JACKET                      FEP              2.68±0.12mm      BLUE



* SPCW: Silver Plated Copper clad steel Wire

* SCT: Silver-plated Copper Tape

* SPC: Silver Plated Copper

* FEP: Fluorinated Ethylene Propylene



ELECTRICAL DATA



ITEM                              SPECIFICATION



CAPACITANCE                   95.1 pF/m (29.0 pF/FT) (nom.)

CHARACTERISTIC IMPEDANCE  50±2

CONDUCTOR RESISTANCE         64.3 Ohms/MFT at 20 C (max.)

OPERATING FREQUENCY           18 GHz

OPERATING TEMP                  -55 +165

SHIELDING EFFECTIVENESS      100 dB (max.)

TIME DELAY                      1.45 ns/ft (nom.)

VELOCITY OF PROPAGATION     70.0 %

RoHS Compliant                              YES

WEIGHT                             21 kgs/Km

MAXIMUM ATTENUATION

Frequency (MHz)                dB/100ft (dB/M)               Power (Watts)

               500                12.0[0.39)               -

             1,000                22.0[0.72)               -

             5,000                51.0[1.67)               -

            10,000                77.0[2.52)               -

             18,000               110.0[3.60]               -
